Brand New LED RGB Mega Bar Strobe Wash DJ Light 648 DMX/piggy back Linkable
This 220mW RPM 3 Colors DJ Laser Light is a unique product that is very different from other colorful lasers, which can be used for lot of more circumstances. Those other lasers' color cannot be separately selected but this laser can.
ORDER ONLINE NOW OR CALL 1-866-606-3991
Features:- Four modes in one: Sound active, AUTO, DMX512, Master/Slave for different applications.
- Advanced design program, more than 100 laser patterns, unique blanking effect Micro-step motor scanner, big angle scanning
- When using this laser, the effect will be changed follow the music. When you change the sound and rhythm, the machine will change its speed and direction.
- SOUND ACTIVE or AUTO MODE
ORDER ONLINE NOW OR CALL 1-866-606-3991
Specifications:- Number of LEDs : 648leds ( Red + Blue + Green )
- Power Consumption : 50W
- Beam Angle : 25°
- Projecting Distance : 10-15Meter
- Led Expected Life : 80,000 hours
- Control system :DMX 512
- DMX Channel : 7 channels
- Voltage : 110V ,60Hz
- Package Dimension : 85cm x 19cm x 19cm
- Weight :3.8kg
LED DISPLAY
No. Display Function 1 A001 7 channels , 28channels, address code(001-512) 2 CC00 7 Color jump change(01-99) 3 CP00 7 Color gradually change(01-99) 4 CS00 Select from 7 color(01-99) 5 LA00 Strobe from slow to fast(01-99) 6 DE00 7 color mix combinations change(01-99) 7 JLBE Sound Active Change
ORDER ONLINE NOW OR
CALL 1-866-606-3991
DMX512channels
Channel Function Details 1 Master Dimmer From dark to bright 2 Master Strobe From slow to fast 3 Program select 0—40:DMX 7 channels control 41-80: DMX 28 channels control, 81—120 : Jump change 121—160:Gradual change, Pulse change 161—200: Run change 201—240 :Jump/Gradual/Pulse/Run Change 214—255: Sound Active 4 Speed From slow to fast 5 Red dimmer From dark to bright 6 Green dimmer From dark to bright 7 Blue dimmer From dark to bright
ORDER ONLINE NOW OR CALL 1-866-606-3991
41-80: DMX 28 channels control
- DMX 8 Chanel,Master team 2, R Dimmer
- DMX 9 Chanel,Master team 2, G Dimmer
- DMX 10 Chanel,Master team 2, B Dimmer
- DMX 11 Chanel,Master team 2, W Dimmer
- DMX 12 Chanel,Master team 3, R Dimmer
- DMX 13 Chanel,Master team 3, G Dimmer
