| Operating Voltage |
8 to 30 VDC |
Works with 12 or 24 volt DC power supplies. Do NOT exceed 30 VDC. |
| Maximum Operating Current |
14 amps continuous 16 amps intermittent |
The linear actuators used in this kit only draw 9 amps. The tracking electronics can handle up to 16 amps. |
| Corrosion Resistance |
Conformal coating on all circuit boards |
Conformal coatings are generally applied to circuit boards that are
used outdoors. They protect the electronics from moisture (humidity) and
corrosion. |
| Moisture Ingress Protection |
IP65 Rated Enclosures |
Protects electronics from moisture. |
| UV Protection |
Wire and Enclosures are UV protected |
Both enclosures and all cable is outdoor rated and UV resistant. |
| Reverse Polarity Protection |
Yes |
If positive and negative power supplies wires are accidentally
connected backwards, the internal fuse on the circuit board will blow
and protect the electronics. |
| Short Circuit Protection |
Yes |
If any of the external wires are accidentally shorted together, the
internal fuse on the circuit will blow and protect the electronics. |
