Basic Kit Heavy-Duty
Sliding Gate Opener
This Basic Kit Heavy-Duty Sliding Gate Opener is designed for residential/commercial applications. Stay
warm and dry in your vehicle. This Sliding Gate Opener will handle single
swinging gates up to 100 ft in length and weighing up to 5700 lb. ORDER ONLINE NOW OR
CALL 1-866-606-3991
Features:
- Sliding Gate Opener opens super heavy gates up to 5700lbs
- Supports up to 6 Remotes, 2 included
- Supports up to 100 Remotes with LM 138 (optional, not included)
- User programmable and user erasable remote codes
- Auto-Close Feature
- Power Supply: AC 110V
- Operating Time: 20 seconds ~ 100 seconds
- For your safety, this model will stop and reverse if is encounters an obstruction on closing and stop when it encounters an obstruction on opening
- Manual key release design for emergency purposes
- Auto-close feature is available for this operator
- Pedestrian mode
- AC Single Phase Motor
- Control panel with interface for photocells, loop detector,
ORDER ONLINE NOW OR
CALL 1-866-606-3991 Includes:
- Basic Kit Heavy-Duty Sliding Gate Opener
- 20 Feet Chain
- 2 Remotes
- 1 (One) Mounting base
- Wireless Keypad, Photocells, Push-button
- 1 Set of mounting hardware for easy installation
- Manual with step by step installation instructions
Specifications:
- Basic Kit Heavy-Duty Sliding Gate Opener
- Power supply AC 110V60Hz
- Opening Gate Speed 12m/min Output torque >= 12 N m
- Motor speed 1400 rpm
- Type Limit switches: Magfnetic limit switch
- Remote control distance >= 30 m
- Weight 35.7lb Noise <56 dB
- Environmental temp -50°C ~ +65°C
- Max gate weight 1300Lb or 600KG
- Output shaft 58.5 mm
- Output power of motor 300W
ORDER ONLINE NOW OR
CALL 1-866-606-3991
|
|
|
 |
|
 |
|
|
|
